Overview:

• The Brainstorm SR-112 Timecode Distripalyzer is an excellent solution for live show applications. It effectively reshapes and distributes timecode across its 12 outputs, ensuring optimal timecode performance.

• This device is capable of sending timecode over long cable runs without signal degradation. It also includes features for analyzing, generating, and repairing timecode, even synchronizing with video when necessary.

• The SR-112 boasts a front panel that conveniently displays timecode information in hours, minutes, seconds, and frames. It accepts timecode input through a single 3-pin XLR port and provides multiple output options, including one DB-25, two 3-pin XLR, and two 1/4" TRS ports.

Distributor and Reshaper:

• The SR-112 functions as both a distributor and reshaper for timecode signals. It ensures that the timecode signal is accurately shaped before distribution, eliminating distortions and fluctuations.

• Each output can be individually adjusted to maintain constant levels for reliable performance.

• With 12 balanced and buffered outputs, the SR-112 ensures consistent and high-quality timecode distribution.

Timecode Analyzer:

• The front panel of the SR-112 offers valuable insights into the timecode. It displays the timecode format, drop frame status, and incoming timecode frame rate.

• The device can also detect and display errors and faulty addresses directly on the front panel display.

• For post-production purposes, the SR-112 accurately monitors the phase between timecode and video, ensuring precise synchronization.

Optional Features:

• Users have the option to enhance the SR-112 with additional features.

• An optional TCG (Timecode Generator) module is available, enabling both timecode repair and the generation of new timecode as needed.

• For convenient control and integration with computer systems, an optional serial port is provided, allowing users to send and receive serial commands from their computers.
